⚙️ I. Power and performance advantages
1. High efficiency and low consumption
Adopting Yuchai's proprietary piston ring sealing technology and No.Ⅰ reinforced high-pressure oil pump, the fuel consumption rate is only 225g/kW-h, and lubricating oil consumption is more than 20% lower than that of similar products in China136 .
Super load capacity: 110% of the rated power (i.e. 19.8KW) can be continuously output within 1 hour, adapting to the sudden increase of load demand27.
2. Reliable and durable
Alloy cast iron body and integral crankshaft design, overhaul cycle of more than 10,000 hours, low failure rate14.
Closed water circulation cooling system ensures stable operation in high-temperature environment; double-sided electrostatic spraying radiator is equipped as standard, with high heat dissipation efficiency36.
3. Environmental protection and low noise
Emissions in line with the national standard GB/T13032-91 and European standards, small vibration, open-frame noise of about 100dB (A) (from 1 metre); optional mute box can be reduced to 68-75dB (A) (from 7 metres) 237.
🌊 Second, application and adaptability
Widely applicable scenes
1. Suitable for ships (passenger/cargo ships, fishing boats), industrial and mining enterprises, high-rise buildings, etc., as common or emergency power 28.
2. Strong altitude adaptability: full power output is available in the environment below 2000 metres, with less performance degradation at high altitude24.
3. Compact and portable design
Dimensions 1600×700×1000mm, weight 600kg, public steel frame base with shock absorbing device, easy to move and install 36.
Intelligent control and security
1. Digital control system (optional high matching)
It supports remote control, group control, automatic parallelism and fault protection (such as overspeed, low oil pressure, high water temperature, etc.)78.
The standard controller is equipped with one-key start/stop, three-phase voltage/current/frequency real-time monitoring, and ‘automatic-manual-disconnect’ multi-mode switching.
2. Multiple protection mechanisms
Emergency stop button, voltage/frequency fluctuation automatic adjustment (steady state voltage fluctuation rate ≤ ± 0.5%), to ensure the safety of the equipment 35.
🛠️ IV. Maintenance and Service
1.Long cycle warranty
Provide 14 months or 1500 hours of three packages (the longest in the domestic industry) 48.
2.National Service Network
Covering more than 1,168 service stations, fast response within a 50-kilometre radius, support for technical advice and parts supply278.
💎 Summary
Yuchai 18KW unit takes ‘low fuel consumption, strong overload, high altitude adaptation’ as its core advantage, taking into account intelligent and low noise design, especially suitable for ships, emergency power supply and remote areas. Its long-life structure and national warranty service further reduce the full-cycle cost of use. For detailed technical parameters (e.g. 10L oil capacity, Y-type three-phase four-wire wiring, etc.) or supplier information, please refer to the source.
| Generator Model | Generator Power (KW) | Generator Power (KVA) | Generator Standby Power（KW) | Generator Standby Power(KVA) | Engine Model | Engine Brand | Engine Rated Power (KW) | Engine Max Power | Cylinder | Bore*Stroke(mm) | Diesplacement(L) | Type | Aspiration mode | Fuel System | Fuel consumption(g/kw.h) | Fuel consumption(L/H) | Start mode | Size（M) | Weight(KG) | |
| 16 | 17.6 | 20 | 22 | YC4V35-D20 | 23 | 1500 | 25/1500 | 4 | 89*100 | 2.5 | In-line;4-Cycle | Natural aspiration | Electronic speed regulation | 240.7 | 7.2 |
